The optical fiber unit is positioned in the center. Two parallel Fiber Reinforced Plastic (FRP) are placed at two sides. A steel wire as additional strength member is also applied.Then the cable is completed with block or color LSZH sheath. It has 1-12 fibers and 900um tight buffer fiber.

GJYRCZY Fiber Optic Cable has a metallic steel wire or Kevlar yarn member which supports the cable, Outer jacket is a UV and flame resistant LSZH.

1. Good UV and flame resistant.

2. Figure 8, tight-buffer design

3. Compact, soft, flexible, easy to install

4. Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property

5. Single steel wire or massagers as the additional strength member ensure good performance of tensile strength.

6. Simple structure, light weight, and high practicability;

7. Novel flute design, easily strip and splice, simplify the installation and maintenance;

8. Low smoke, zero halogens, and flame retardant sheath

9. Subcable flame-retardant jacket;

10. Excellent stripping performance of tight buffer fiber;

11. Suited to SM fiber and MM fiber (9μm, 50μm, and 62.5μm).

Optical Characteristics:

Technique Parameters:
